Product Description

Pulsating Vacuum Rectangular Pressure Steam Sterilizer With the features of PLC and man-computer interface automatic program control, automatic temperature recording, vacuum drying, etc. it is suitable for hospitals, pharmaceutical factories, scientific research institutes and other units to sterilize and dry clothing, dressings, metal instruments ,culture medium, dressings, etc.

Structure & Capability & Characteristics:
Patent door lock device.
Piston-driving device is the pioneer in the same occupation in domestic market. It is easy operation without maintain. The reliable mechanical electric interlock make ensure the safe operating.

Reliable stabile micro-computer automatical control and advanced function for recording, printing and storing, etc.

As the main system controller, touch-screen+PLC is selected worldwide well-known brand and reliable. In the matter of data managing, the real-time print or CF store can be choosed.

Horizontal rectangle main body, designed and produced according to <Steel Pressure Vessel> standard and <Pressure Vessel Technical Detection Regulation>
The main body is consisted of inside and outside layers which is good for pre-heat drying and continuously operation during sterilizing. The inside layer is made of SUS304 stainless steel, polished, smooth, no corrosion and anticorrosive.

Inner gas-filled gasket ring with good performance, heat-resisting, excellent flexibility and serviceable.

The gasket ring is made of good quality silicone rubber which can resist 200 C and higher temperature. The unique inner gas-filled structure ensure the seal tightness.

Elegant decorate cover
The cover is made of wiring-drawn stainless steel, good outlook, serviceable and easy to clean.
Excellent heat preservation dealing.
The heat preservation layer is made by locale foaming technology with polyurethane material to obtain the best result.
Pressure holded inactivate and inactivate container inactivate system can be fixed according to P3P4 Lab requests.
The GMP confirmation access is fixed for the customer to do GMP confirmation.

Main Parameters and Utilities
Design Pressure: 0.245Mpa
Working Pressure: 0.22Mpa
Design Temperature: 139
Working Temperature: 134
Heat equilibrium: ≤1
Vacuum: 0.095Mpa
Steam Pressure: 0.4-0.6Mpa
Water Pressure: 0.1-0.3Mpa
Compressed Air Pressure: 0.5-0.7Mpa

Model Overall Dimensions L*W*H (mm) Single/Double Door Chamber Size L*W*H(mm)
YG-0.2 895*1220*1720   700*600*600
YG-0.3 1195*1220*1720   1000*600*600
YG-0.6 1245*1300*1880   1050*680*850
YG-0.8 1595*1300*1880   1400*680*850
YG-1.2 1695*1370*1960   1500*750*1100
YG-2.5 3195*1370*1960   3000*750*1100
YG-5.0 3635*1800*2200   3400*1000*1500.
