Product Description
This equipment adopts high performance PLC testing control, two operating systems (manual and automatic) and standard interfaces qualified by GMP. With the following advanced functions, lick pre-vacuum, high temperature quick sterilization quick cooling after sterilization and special anti-pressure protection device, this equipment can reliably sterilize all kinds of damp-heat resisting products in bulk, bottle, can and soft package.
Structure & Capability & Characteristics
1) The box is designed, produced and tested strictly according to the 《Steel Pressure Vessel》
2) Pneumatic translational door, easy to operate, flexible
3) The unique dove-tail inlaid design of heat-resisting silicone rubber gasket ring ensures the seal tightness of the door.
4) The main control system adopts micro-computer PLC+ touch screen + DCS long distance tiring-room monitoring system
5 Elegant stainless steel decorate cover
6 The heat preservation layer is made by polyurethane material and pearl rock wool
7 The GMP confirmation access is fixed on the equipment
8 Constituted frame sterilizing cart
9 Excellent rapid cooling device
Model Overall Dimensions L*W*H(mm) Chamber Size L*W*H(mm)
KG-1.2 1695*1370*1960 1500*750*1100
KG-2.5 3195*1370*1960 3000*750*1100
KG-3 2235*1800*2200 2000*1000*1500
KG-5 3635*1800*2200 3400*1000*1500
KG-8 5635*1800*2200 5400*1000*1500
KG-10 6935*1800*2200 6700*1000*1500
Main Parameters and Utilities
Design Pressure: 0.245Mpa
Working Pressure: 0.22Mpa
Design Temperature: 139
Working Temperature: 134
Heat equilibrium: ≤1
Vacuum: 0.095Mpa
Steam Pressure: 0.4-0.6Mpa
Water Pressure: 0.1-0.3Mpa
Compressed Air Pressure: 0.5-0.7Mpa.
