1. Geocell Applications:
to stable the bed of railway and road
to bear the bed of road
to bear the loading dykes and walls
to administer shallow water and river
to support pipeline and sewer
to prevent landslide and to be used as compound walls to support loading
to be used in dependent walls,wharfs and bank and so on
to govern sand,beach,river bank and riverbed
Geocell Technical Parameter
Product Type Height
(mm) Welding Distance
(mm) Thickness
(mm) Tensile Strength
of Welding Points(N/cm) Tensile Strength of
Connection of Cells(N/cm) Tensile Strength at
Yield of Each Sheet(N/Mpa)
Flat and Not Perforated 50≤H≤250 330≤A≤1000 1.1/1.2 ≥100 ≥120 ≥20
Flat and Perforated 50≤H≤250 330≤A≤1000 1.1/1.2 ≥100 ≥120 ≥20
Embossed and Not Perforated 50≤H≤250 330≤A≤1000 1.5 ≥100 ≥120 ≥20
Embossed and Perforated 50≤H≤250 330≤A≤1000 1.5 ≥100 ≥120 ≥20
Remarks:Width of the product can be made according to the
 customer's demand, and the other special standards
will be carried out by agreement or contact.
Geocell Specification
 1.Height:50mm-200mm
 2.Welding distance:330mm-1000mm
 3.Thickness of sheet: 1.0mm-1.5mm
 4.Material hdpe with density of 0.935~0.965g/cm3 0.94 g/cm3 ASTM D 1505
 5.Seam peel strength 1420N/10CM
 6.Minimum ESCR 4000hr at least
 7.Tensile strength of strips 22Mp min
 8.Carbon Black Content 2% min ASTM D 1603
