Main advantages compared with traditional washing:
The Film Dry washing machine has improved the quality of products and the output of materials. As the recovered material is dry, the energy required for extrusion is reduced. The cost per ton of dry washing is 30% lower than the cost of conventional washing.
Equipment maintenance also saves cost. Because the impurity separation is very clean, the damaged parts such as screw, barrel and filter of the subsequent pelletizer/granulator can be effectively protected. No bubbles were generated during the processing, and the replacement time of the screen filter was prolonged. For screw and barrel, their service life is also extended to two times than original ones.
Technical parameters of film dry washing drum
1.Motor power: 55kw
2.Driving way: wheel drive
3.Diameter: ф2100mm
4.Height: 625mm
5.Screen: ф685-ф1610mm
6.Outlet size: 267×247mm
7.Drum diameter: ф2416mm
8.Air pump pipe
9.With discharge tank
10.Dimension:4760*3200*3500mm
