Description

                Among all network video solutions, Clairvoyant1002 is the most cost efficient and is especially suitable for all broadband users. Clairvoyant1002 comes with RJ-45 port, support DHCP, PPPoE ADSL dial-up and DDNS client.

       Clairvoyant1002 is an economical model of advanced IP camera device. It comes with many high quality features, yet costs relevantly low. Clairvoyant1002 works standalone with broadband connection allows remotely viewing of images by Microsoft IE browser anywhere, any time.

       Just like any network device, with its own IP address, Clairvoyant1002 connects directly to a standard network switch or to a wireless network. This enables viewing real time digital video over the LAN or Internet from all over the world.

   Clairvoyant1002 uses existing Network (IP) technology.  In a case of surveillance project, using existing IP network infrastructure combining with Clairvoyant1002, extra costs related to traditional installation and deployment of analog CCTV surveillance systems (such as coaxial cables, monitors and video recorders) can be eliminated.

   Clairvoyant1002 is designed around a powerful camera platform. A genius embedded WEB server and real-time operating system with Standalone Motion Detection alarming guarantee 24/7 operation in the most demanding of environments.

Feature Highlights

-  A least cost solution for remote monitoring;

-  A highly developed on-board image processor;

-  An inbuilt WEB server and standalone motion detection;

-  JPEG and MJPEG video compression;

-  Access by IE browser, no complicated client software required;

-  View 1 or 4 cameras image on IE screen;

-  Recording on IE screen, playback by media player;

-  Simultaneous Multiple Accesses from remote, LAN or Internet;

-  Additional security is provided through password protections for the camera;

-  Standalone motion detection and alarm input to trigger snapshots;

-  Email snapshots enable sending alarm notifications to assigned e-mail boxes;

-  Send snapshots to FTP server;

-  Easy IP camera tool & quick install guide are included in product CD;

-  PPPoE & DHCP accompany with DDNS service;

-  Connect to ADSL/Cable Modem or NAT router;

-  Monitoring/ video recording is included in hardware;

-  10 meters effective IR lamination by 24 IR Leds (outdoor version) ;

-  IEEE 802.11g/b 2.4GHz Wi-Fi with WEP 64/128 bits protection.

Market Applications

Due to the benefits of our low costs strategy, new business applications can be implemented and integrated with Clairvoyant1002, such as:

-  ISP promotional bundles

-  VoIP telephone tie-in to be video phone

-  Live video embedded into homepages, online advertisement

-  Remote Control / Vehicles Control / Chain stores Control / Advertising / Traffics Alerts

-  Baby and elderly tending

-  Private Security/ Caring

Technical Data

Image System

-  Compression: Motion JPEG hardware compression

-  350,000 pixels CMOS sensor

-  f: 6.0mm to infinity, C/CS mount lens

-  Min. 2.0 to 3.0 Lux  (Indoor version)

-  Min. 0 Lux with IR Leds  (Waterproof IR version)

-  Automatic Exposure Control

-  Automatic Gain Control

-  Automatic Brightness Control

-  Automatic White Balance

-  Flicker Avoidance (Flicker less)

-  Resolution:

QVGA (320 x 240)

   VGA (640 x 480)

-  Image Frame Rate:

Max. 25 fps at QVGA resolution, average 4 Mbps/sec

Max. 15 fps at  VGA resolution, average 4 Mbps/sec

-  I/O Interface

CAT5, RJ-45 x1 (802.3)

RS-485 for PTZ control  (OEM indoor version)

IEEE 802.11g/b Wi-Fi with WEP

Alarm in, Alarm out

Network Protocols

-  TCP/IP, HTTP, ARP, ICMP, PPPoE, DHCP, SMTP, DDNS, FTP

Client

-  IE6

Mechanical & Environment
