Product Description
RATE LOAD(t): 5、10、20、50、100、150、200、300、500
FEATURES: Alum alloy structure, High precision / low capacity / High stability.
APPLICATIONS: Used abroad in every kind of electronic weighing equipments like Portable scales / Tension or compression application etc
|
PARAMETERS:
|
|
Precision : C2
|
|
Output Resistance(O ) :350±10
|
|
Comprehensive Error(%F.S) : 0.03
|
|
Insulation Resistance(MO):
≥5000(100VDC)
|
|
Rated output(mv/v) : 2.0±0.002
|
|
Excitation Voltage(V) : 9~12(DC)
|
|
Non-linearity(%F.S) : 0.03
|
|
Compensated temp.Range(℃ ) : -10~+40
|
|
Hysteresis(%F.S) : 0.03
|
|
Use Temp. Range(℃ ) : -35~+65
|
|
Repeatability(%F.S) : 0.01
|
|
Temp.Effect on Zero(%F.S/10℃) : 0.03
|
|
Creep(%F.S/30min) : 0.02
|
|
Temp.Effect on Span(%F.S/10℃):0.03
|
|
Zero Balance(%F.S) : ±1
|
|
Safe Overload (%F.S) : 150
|
|
Input Resistance(O) :350±3
|
|
Defend Grade :IP65
|
