PL-24D Copper-clad aluminum fine wire Drawing Machine machine parameter
machine type
24D
inlet diameter(mm)
φ0.5-φ1.0
outlet diameter (mm)
φ0.1-φ0.4
drawing line speed(MPM)
2000
drawing dies No./Max
24
slip ratio of m/c
10.5%
fix speed capstan slip ratio
6%
capstan
ceramic plasma
capstan dia.(max.)(mm)
φ180
fix speed capstan dia. (mm)
φ180
frame
ironed cast
main motor
7.5KW three phase inductor motor
spooler motor
2.2KW three phase inductor motor
revise system
PID synchronous spooler
inverter control
Dual inverter control
transmission type
flat belt
send-out method
over head
traversing unit
flat belt + timing motor
tension control
pneumatic balance by swing arm
lubrication system of wire drawing
spray
suitable diameter of spool (mm)
φ300
capacity for wire receiving(kg)
30
bobbin loading & unloading type
shaft type
power source
380V
brake
machine dimension
machine dimension
1900L×1350W×1750H
machine weight
2200
zhangjiagang poly machinery and electric manufacturing Co.,Ltd
Company Introduction
CHINA Zhangjiagang Poly Machinery and Electric Manufacturing Co.,Ltd is a professional manufacturer of making wires and cables machinery. The main products include EDM Brass Wire Drawing Machinery .cca machine.cca product line .annealing-tinning machine .medium Wire Drawing with continuous annealing Machine. wire drawing machine for copper wire,brass wire, EDM Brass Wire, Brass EDM Wire,copper-clad aluminum wire,cca wire,Copper-clad steel wire,Stainless steel wire.
