Product Description
DS6-15 Block Machine
DS6-15 type block making machine is made of Germany, Italy, Japan technology, compatible with the road blocks, road-side bricks and river bricks, meanwhile the second fabric can be chosen to expand effects of bricks color. Adopt sub-storage device, independent storage hopper to overcome the liquefaction of concrete defects in advance, insure the quality of the finished products quality. It can automatically operate the whole set, from material feeding to finish products output.
Functions and features:
■Adopt large strong steel, super-strength design and manufactured by special welding techniques and materials, high-rigid, resistant to vibration, long service life. Adopt four-oriented approach to insure the pressure head and mold box move exactly with good stability, and wide fixed mold plate for mold box, with the replacement of various models of multi-purpose tool of a machine to meet the various needs.
■The host machine adopt hydraulic rotational molding and vibration compression molding. Molding cycle takes 15 - 18 seconds to leave the floor for forming health, and spend a lot of floor investment.
■Hydraulic mainly sent to the respective board or backplane, feed, back feed, compression extrusion products, mechanical secondary, sending bricks with each other to shorten the molding cycle.
■Forced feeding, the traditional feeding method is difficult to feed materials evenly to mold box, DS6-15 box-type machine equipped with a multi-fabric mixing fork, mold box to the top of mixing fork work on mandatory feed box.
Main technical parameters of DS6-15 hydraulic block making machine:
|
Parameter Name
|
Parameter values
|
|
The largest machine dimensions
|
6600×1990×3000（L×W×H）(mm)
|
|
Rated pressure of hydraulic system
|
21Mpa
|
|
Main vibration form
|
All vibration molded desk
|
|
Vibration frequency
|
50~70Hz
|
|
Vibration acceleration
|
10-15g
|
|
To adapt to the high brick
|
50-200mm
|
|
Pallet size
|
Wooden
|
830×660×（40±1）（mm）
|
|
Iron
|
830×660×（8-10±1）（mm）
|
|
Bamboo
|
830×660×（15-20）（mm）
|
|
Molding cycle
|
15-18 seconds 20-23 seconds to be added fabrics
|
|
|
When production
|
Standard block（240×115×53mm）
|
57,600 Pieces/ 8 hours
|
|
Feeder capacity
|
Effective storage volume of 0.45m3 hopper
|
|
|
Effective volume of 0.15m3 car charging
|
|
Machine power
|
36.8kw
|
|
Machine weight
|
12T
|
|
Brick shaped mold can be produced according to user needs.
|
Main product specifications and production of each plate:
|
Model
|
Block Specifications (mm)
|
Forming number
(Block)
|
Molding cycle
(Seconds)
|
Middle class
(8 hours) (block)
|
|
DS6-15
|
390×190×190(block)
|
6
|
15
|
11520
|
|
240×115×90(brick)
|
15
|
15
|
28800
|
|
240×115×53(standard brick)
|
30
|
15
|
57600
|
|
·This series of 150-650 tons of products with different specifications. Brick shaped mold can be produced according to user needs.
|
|
Production conditions
|
|
Production sites
（m2）
|
Venues
|
8-10acres
|
|
Operate camp
|
60
|
|
Raw space
|
300
|
|
Office space
|
30
|
|
Other conditions
|
Staff
|
8-10people
|
|
Distribution
|
40kw
|
|
Water
|
10T/day
|
