Product Description
六排抽式盒装面巾机
Box-Type Tissue Napkin Making Machine (Four to Six Routes)
JWC-CJ4-6
主要功能与特点
◎抽式盒装面巾机是将原纸经刀辊剪切,交互折叠成铰链式的长方形叠纸。本机采用真空吸附。
◎自动计数分叠装置,具有速度快,数量准确等优点。(可加装压边纹装置)
◎机器型号:CJ4-6
◎制品尺寸(mm):200x200(其它规格请指定)
◎原纸宽度(mm):800~1200
◎原纸尺寸(mm):Φ1000(其它规格请指定)
◎原纸芯内径(mm):76.2(其它规格请指定)
◎加工能力:1000-1400张/分(印花),2500-3200张/分
◎编程控制器:PLC电脑编程
◎压花装置:钢对胶辊,钢对钢压花
◎压花底辊:毛布辊,羊毛辊,胶辊
◎压光:钢对钢,钢对胶
◎压边纹:钢对钢,独立调节
◎对边系统:需订购
◎分切系统:气动式点切
◎加油系统:关键部分自动定期加油
◎传动系统:同步带
◎计数系统:错位分叠计数
◎动力:变频调速 5.5-11KW
◎真空系统:11-32KW
◎气动系统:3匹空压机,最少压力5kg/cm2 Pa(客户自备)
◎外型尺寸(mm):5250x1800x2000
◎机器重量:6200 ~8500kg
选配项(需订购)
◎编程控制器:PLC,人机界面
◎使用动力:变频调速,电磁调速
◎传动系统:同步带,链条
◎压花装置:钢对胶辊,钢对钢压花
◎压花底辊:毛布辊,羊毛辊,胶辊
◎分切系统:气动式点切,全切
◎压边纹:钢对钢,独立调节
◎压光:钢对钢,钢对胶
◎真空系统:罗茨风机
◎对边系统:需订购
Main Function Features
◎The jumbo rolls which have been silt into the desired width are cut by the slitting cylinders, and then inter folded into inter-overlapped rectangular facial tissue sheets. The machine adopts vacuum suction, and automatic making function. It features of high speed, nice folding and easy operation.
◎Machine model: JWC-CJ4-6
◎Finished Products Size (mm): 200x200(Other sizes are available)
◎Machine Width (mm): 800~1200
◎Raw Material Diameter (mm): Φ1100 mm (Other sizes are available )
◎Raw Material Core Diameter (mm):76(Other sizes are available)
◎Speed: 3800-5000 sheets /min
◎Programmer Controller: PLC Programmable Controller
◎Embossing Unit: Steel to rubber embossing, steel to steel embossing
◎Bottom Embossing Roller: Felt roller, Paper roller, Rubber roller
◎Calendaring: Steel to steel, steel to rubber
◎Edge Embossing: Steel to steel, independent adjustment
◎Jumbo roll guiding system: Optional
◎Slitting unit: Pneumatic dot slitting
◎Lubricating system: Key parts regularly lubricating automatically.
◎Driving system: Timing belt driving system
◎Counting system: Alternate stack by stack
◎Main Motor Power: Frequency converter to control the speed 5.5-11KW
◎Air Pump Power: 11-32KW
◎Pneumatic System: 3HP air compressor, mini pressure 5kg/cm2Pa(Provided by client)
◎Dimension(mm): 5250x1800x2000(LxWxH)
◎Weight: 6200-8500kg
Optional device
◎Programmer Controller: Programmable Controller (PLC), LCD touch button
◎Power: Variable frequency
◎speed control: Electromagnetism speed control
◎Driving system: Timing belt, chain
◎Embossing Unit: Steel to rubber embossing, steel to steel embossing
◎Bottom Embossing Roller: Felt roller, Paper roller, Rubber roller
◎Slitting unit: Pneumatic dot slitting
◎Edge Embossing: Steel to steel, independent adjustment
◎Calendaring: Steel to steel, steel to rubber
◎Pneumatic System: Roots vacuum pump
