Application:

Series TYA vacuum lube oil purifier is mainly for purifying unqualified lubricating oil, hydraulic oil, compressor oil, refrigeration oil and other industrial oils, this machine can rapidly separate water, gas, particles and volatile matter (such as alcohol, gasoline, ammonia, etc.) from oil, restoring oil viscosity, flash point and performance. The treated oil can reuse again in various industrial equipments. It is widely applied in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway etc.

Features:

1. Double primary-filter structure, large capacity for holding particles, Multi-stage filtration system to ensure high filtration precision.

2. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles

3.Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively remove water, gas, particles and volatile matter (such as alcohol, gasoline, ammonia, etc.)

4. Automatic backwashing system, improving working efficiency

5. Advanced medium cooling system

6. High quality filtering components, large capacity for holding particles, anti-corrosion, good mechanical performance, long lifetime.

7. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

8. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.

Technical Parameters:

Index name   Unit TYA-10  TYA-20  TYA-30  TYA-50  TYA-100       TYA-150       TYA-200       TYA-300

Flow rate       L/H  600 1200      1800      3000      6000      9000      12000    18000

Working vacuum  MPa       -0.06~-0.095

Working pressure       MPa       ≤ 0.4

Temperature range           20 ~80

Demulsifying value      min  ≤15/min(GB/F7035)

Water content      ppm       ≤100

Gas content  %    ≤ 0.1

Cleanness           ≤ NAS 6 grade

Power supply              380V 50HZ 3Ph (As per user's option)

Working noise      dB(A)     ≤65~80

Heating power      Kw   36   40   45   60   80   110 145 160

Total power   Kw   38   42   47   65   96   124 157 178

Inlet(Outlet)   mm  Φ25       Φ25       Φ25       Φ32       Φ42       Φ50       Φ50       Φ60

Weight   kg   350 380 400 450 750 880 1100      1300

Dimension     L     mm  1500      1500      1500      1600      1750      1900      1950      2100

       W    mm  1000      1050      1050      1150      1150      1600      1600      1700

       H     mm  1600      1600      1650      1700      1750      1950      1950      1950
