Product Description
Specifications:
Overall Length(mm): 1960x805x1080mm
Wheelbase (mm): 1295mm
Ground Clearance(mm): 180mm
Dry Weight(kg) : 115kg
Max. Load Mass(kg): 150kg
Max. Speed(km/h): 85km/h
Tire: Front: 2.75-18 Rear: 3.50-16
Driving Mode: By Chain
Brake Mode: Front: Plate Rear: Drum
Brake Operation Mode: Front: By Hand Rear: By Foot
Engine: JL157FMI
Engine Type: Single Cylinder Four Stroke
Cylinder Type: Vertical
Bore X Stroke(mm): Dia.56.5 X 49.5(mm)
Piston Displacement: 124.5cc
Compression Ratio: 9.5:1
Max. Torque(N.M/rpm): 8.8/6000(N.M/rpm)
Lubrication: Compress & Splash Combined Type
Max. Output Power: 7.2/8000(kw/rpm)
Ignition: C.D.I
Started System: Electric Starter/Kick Starter
Engine Cooling: Forced Air Cooling
Transmission: Five Speed International Gearshift
Clutch: Manual, Wet, Multi-Disc
Battery: 12V-7AH
Fuel Capacity: 8.4L
Average Consumption: 2.5L/100km
Shipping Size: Front wheel and handlebar knocked down
Packing Size (LxWxH): 1700 X 460 X 870 mm
Weight: Net Weight: 115kgs
Gross Weight: 145kgs
Quantity of Container:
20'FCL: 32 units
40'FCL: 68 units
40'HQ: 102 units
