Medical Ti6AL4V rods

Negotiable / Piece(s)

Min. Order 1 Piece(s)

Baoji Litai Non-Ferrous Metal Co., Ltd

Medical Ti6AL4V rods

Price: Negotiable / Piece(s)
Min. Order: 1 Piece(s)
Stock: 0
Port

Send Inquiry Favorite

Baoji Litai Non-Ferrous Metal Co., Ltd

Location:: Shaanxi,China
Main Category:: Metals and Minerals
Main Products:: Titanium bars,Medical titanium rods,Titanium hexagonal rods,Titanium wire,Titanium plate,Titanium tube,Titanium forgings,Titanium capillary,Titanium foil,Memory

Contact Info.

Product Description

Medical Ti6AL4V rods

My company is a professional production titanium rod and medical titanium manufacturer,Production of various specifications and of,Titanium bars,Medical titanium bars,Titanium alloy bars,Memory alloy ,Surgical implantation use Titanium bars/rods (Ti6AL7Nb,Ti6AL4V ). Company's product quality stable,Product quality conforms to ASTM standards(Dimensional Inspection ,Microstructure ,Macrostructure,Chemical composition, mechanical properties,Metallographic organization,Tolerance).

Medical titanium bar

1). low dentisity,light

2). corrosion resistance, the normal PH value of body fluid is 7.4,titanium and titanium alloy is the most corrosion resistant in this media.

3). Biological compatibilty .

4). Biological adhesion,that is integration with the bones.

5). Mechanical properties,the elastic modulus of titanium and titanium alloy is comparable to that of human bones.

Grade, Gr5,Ti6Al4V ELI,Gr7,Gr9,TiNi,Ti6AL7Nb,Ti15333.

Making process, smelting-ultrosonic test-forging-rolling-annealing-polishing-ultrosonic test

Size, 2.0---70mm× Length 1000---3000mm ( Rolled )

Size,70---280mm× Length 1000---3000mm ( Forged )

Tolerance , H9 , H7 , H6 .

Delivery status, R , M .

Packing , wooden boxes IPPC .

Standard , ASTM B348, ASTM F67, ISO5832-2ASTM F136, ISO5832-3, AMS4928, MIL4911.

N/BS53 03 – 2002

Grade	State	Mechanical property of the room temperature, not less than
Grade	State	Σb Mpa(ksi)	σo.2 Mpa(ksi)	δ40 %	Ψ %
GR.1	Annealing(M)	241(35)	172(25)	24	30
GR.2		345(50)	276(40)	20	30
GR.3		448(65)	379(55)	18	30
GR.4		552(80)	483(70)	15	25
GR.5		896(130)	827(120)	10	25
GR.7		345(50)	276(40)	20	30
GR.9		621(90)	483(70)	15	25
GR.12		483(70)	345(50)	18	25
