Product Description
Feature
- 16CH Real Time Monitoring/Recording
- 16CH Camera 480 Frame/sec, Real Time Capture Board
- Camera Input: 1~16ch
- Resolution: 640x480, 320x240, 160x120
- Windows 98/2000Pro/XP Pro
- NTSC, PAL Support
Specification
Input Type DB15 X 2
- Video Input(s) 16 Cams
- Audio Input(s) optional (work with GV- A16 Audio Board)
- Recording Rate 480 fps (NTSC), 400fps (PAL).
- Display Rate 480 fps (NTSC), 400fps (PAL).
- Video Resolution
NTSC: 720x480, 720x480 De- interlace, 720 x 240, 640 x 480, 640 x 480 De- interlace, 640 x 240, 320 x 240
PAL: 720 x 576, 720 x 576 De- interlace, 720 x 288, 640 x 480, 640 x 480 De- interlace, 640 x 240, 320 x 240
- Compression Format Wavelet, MPEG- 4, GeoMPEG4
- GV- DSP Support Yes
- GV- A16 Support Yes (what's GV- A16 Board)
- GV- NET/IO Card Support No
- Software V7.0(with USB- Dongle)/V6.1/V6.05
- Dimension 225mm x 103mm
- Note: GV- 1000 is currently not compatible with VIA series chipset motherboard.
