Cast Alnico Magnet

Negotiable / Piece(s)

Min. Order 1 Piece(s)

Yuxiang Magnetic Materials Ind. Co., Ltd

Cast Alnico Magnet

Price: Negotiable / Piece(s)
Min. Order: 1 Piece(s)
Stock: 0
Port

Send Inquiry Favorite

Yuxiang Magnetic Materials Ind. Co., Ltd

Location:: Fujian,China
Main Category:: Metals and Minerals
Main Products:: Magnetic Materials,NdFeB Magnets,AlNiCo Magnets, Ferrite Magnets,SmCo Magnets,Rubber Magnets,Fridge Magnets,Magnetic Powder,Magnetic Compound,Magnetic Assemblie

Contact Info.

Product Description

Permanent cast alnico magnet is a kind of alloy magnets made from Al, Ni, Co, Fe and other trace metal elements and may be produced through either sintering or casting process. The product has remarkable resistance against corrosion and high tempperature, and is mainly used in certain precision instruments.

Alnico magnet characters are as follows,
1, Compact crystal, high intensity, good chemistry Stability, strong anti-corrosion.
2, Even elements, excellent and stable magnetic performance;
3, Excellent temperature stability (temp. coefficient of Br is the smallest among all of the other permanent magnets. )
4, Highest usage temperature reach 500 centigrade.
5, Suitable for small volume and complex shape and magnet assemble for sintered Alnico.

AlNiCo magnets Application are as follows,
1, Inner magnetic voltmeter/ammeter, electronic type power energy measuring instrument, avometer, flow meter;
2, In widely range of magnetic sensor, polarized relay, temperature and pressure controller;
3, Buzzer of Mobile phone, hearing aids, mini speaker;
4, lighter of automobile, odometer of automobile and motorcycle, permanent motor, adsorptive appliance;
5, Widely applied in high stability fields as aviation, space flight and military technology

For more detail info, please feel free to visit our website or inquire us at any of your convenience.

Grade	Br	Hc	(BH)max	Curie Temp	Temp.Coe	US standard	IEC standard
Grade	[mT] [Gs]	[KA/m] [Oe]	[KJ/m³] [MGOe]	[^oC]	[%/^oC]	MMPA Equivalent	IEC Equivalent
LN10	650 6500	42 530	10.0 1.20	810	0.030	Alnico 3	Alnico 9/3
LNG11	720 7200	37 480	11.2 1.40	810	0.030	Alnico 1	Alnico 8/4
LNG13	700 7000	50 620	13.0 1.60	810	0.030	Alnico 2	Alnico 12/6
LNGT18	580 5800	90 1130	18.0	860	0.025	[I.Alnico 8]	Alnico 17/9
LNG16	800 8000	53 660	16.0 2.00	850	0.025	[Alnico 4]	/
LNG34	1180 11800	44 550	35.0 4.30	860	0.020	[Alnico 5C]	/
LNG37	1180 11800	48 600	37.0 4.65	860	0.020	[Alnico 5C]	Alnico 37/5
LNG40	1220 12200	48 600	40.0 5.00	860	0.020	Alnico 5	/
LNG44	1220 12200	52 650	44.0 5.50	860	0.020	Alnico 5	Alnico 44/5
LNG52	1250 12500	55 690	52.0 6.50	860	0.020	Alnico 5 DG	Alnico 52/6
LNG60	1300 13000	56 700	60.0 7.50	860	0.020	Alnico 5~7	/
LNGT28	1050 10500	56 700	28.0 3.50	860	0.020	Alnico 6	Alnico 26/6
LNGT32	800 8000	104 1300	34.0 4.25	860	0.025	Alnico 8	Alnico 38/11
LNGT38	820 8200	110 1380	38.0 4.75	860	0.025		Alnico 38/11
LNGT44	880 8800	120 1500	44.0 5.50	860	0.025		/
LNGT60	900 9000	110 1380	60.0 7.50	860	0.025		Alnico 60/11
LNGT72	1050 10500	112 1410	72.0 9.00	860	0.025	Alnico 9	/
LNGT36J	700 7000	140 1750	36.0 4.50	860	0.025	Alnico 8 HC	Alnico 36/15

For more detail info, please feel free to visit our website or inquire us at any of your convenience.

Website: magnet-tech.com

magnets.com.cn

e-magnet.cn

Yuxiang Magnetic Materials Ind. Co., Ltd

Company Introduction

Yuxiang Magnetic Materials Ind. Co., Ltd. is located in the beautiful coast of southeast sea. Established in 2000, we are an export-oriented enterprise. Now our company becomes an enterprise with advanced technology, owning two factories in China, both of which have their own R&D and QC departments, and are ISO9001:2000 certified. We also have an office in Xiamen to provide you with prompt export support.

We are moving ahead with the aim of producing more advanced, more practical, and more competitively-priced products. We keep close track with the ever-changing trends in the industry, with the objective of spearheading our company in the market. We have an ambitious outlook towards expansion, and operate our business with diligence and sincerity. Our more than 20 years of technical know-how and experience have been keeping us ahead in the industry. We have been in the OEM business for five years and are ready for your orders and special requirements.

We supply hard magnets and magnetic materials from China. Our magnets include ferrite magnets, flexible magnets, NdFeb magnets, alnico magnets, SmCo magnets, rubber magnets, refrigerator fridge magnets, magnetic powder, magnetic compound tesla meters & magnetizers, and magnetic jewelry. We also supply ferrite cores, MnZn cores and NiZn cores for transformers and coils, loudspeaker magnets, motor magnets, and refrigerator gasket stripes. Please feel free to visit our website of http://www.magnets.com.cn for more details.
