·       Application:

o        Flat die pellet mills are generally used for pellet production on a small to medium scale

o        Flat die pellet mills can process a wide range of biomass materials for a range of applications

o        These include wood, straws, grasses and other biomass residues and also for animal feedstuffs

o        Raw material for the pellet mill must have passed through sufficient size reduction before it can be placed in the pellet mill

o        The raw material must have a particle size of 3 to 5mm or below

·       Key specification and quality warranty:

o        Heart parts of the pellet machine-die and roller are made by high alloy steel wear resistant material according to different materials, in order to have longer work lifetime

o        Wood/biomass pellet machine with double layer dies, up and down dual-use, reduce buyer’s cost, so it can reach high capacity and also energy saving

o        12 months limited warranty for electric parts

·       Average lifetime for die and rollers:

o        2,000 hours for SK-350/450/550/800/1000

·       Technical parameters:

o        Capacity: 600kg/H

o        Power: 45kW

o        Drive way: gear box

o        Diameter of pellets: 6 to 20mm

o        Pellet length: which can be adjusted by adjusting knife within range of 1 to 5cm

o        Diameter of the die: 450mm

o        Weight: 1,200kg

·       Dimension:

o        Length: 1,650mm

o        Width: 900mm

o

o        Height: 1,400mm
