Compact 3--Star is the professional diagnostic equipment for Mercedes Benz cars manufactured after year 2000,it is the replacement of HHT.Compact 3--Star operate based on the Windows XP system,it includes workshops information system(WIS system),the movement management system(STARUTILITIES)and the automatically diagnose system(the DAS system)

Function:

reading out and erasing trouble code; reading the real-time data of sensor and actuator; testing the component of cars; coding and programming.

Remark:

● C3 STAR works with original computer (COMPACT 3) via RS485 protocol.

● The maximum transmission length is 100 meters.

● Strong anti-jamming

Configuration:

1.C 3 STAR MULTIPLEXER

2.16 PIN OBD II cable

3.38 PIN cable

4.14 PIN cable

5.4 PIN cable

6.RS232 to RS485 communication cable (navigation port)-- connect with the laptop (9 pins COM)

Optional Configuration:

1. IBM laptop: T30

2. software DAS+WIS+EPC
3.power supply cable(connect with touch screen computer)

4.tool box

Attention: BENZ official factory computer is STAR COMPACT 3, which is a special computer with touched screen which is too expensive.

Software: updated through DVD,
1. DAS:diagnosis and program software
2. WIS:repair management system software (can DAS).
3. EPC: spare parts management system (install alone)
Software upgrade: DVD Disco upgrade,totally the same with the origianl factory.

Diagnosis surface multiplxer features:
A. Realizes all the function of official factory BENZ star 2000.
B. There is a difference in the way of communication. RS485 is used between original factory star multiplexer and original factory computer. But satr multiplexer linked to common computer is RS232 comunication, and our multiplexer is this kind.
C. It is necessary to transfer RS232 RS485 when original factory multiplexer is carried out by common computer, and our company has this cable.
D. The communication socket of original factory multiplexer is 19 pins circular aviation socket, which is expensive, sturdy, durable, and our cable is totally the same to it. Those ordinary 9 pins sector socket sold in the market, which are fairly unreliable, short lifespan, loose in several months, so the contact is not good, and which price is only one out of dozens of aviation socket.
E. Diagnostic socket is usually 55 pins aviation socket.

Diagnostic cable feature:
different from the inferior ones in the market.our cable are totally the same with original ones,which more expensive but firm and reliable in communication with a long lifespan

Packaging:tool box or carton

After sale service
1. Guarantee: one year, from the date equipment arrival

2. Upgrade free for one year

3. Upgrade method: Hard Disk

4. Freight collect

5. Maintenance freight was paid by seller
