Synchronising - Optimize your gen-set usage or parallel different sizes and brands of generators
PLC - Utilise our unique, and easy to use PLC drag-and-drop blocks for configuration.
New design - Flexibility to change the application e.g. SPtM and MINT.
Built in AVRi - You no longer need a separate AVRi interface in your installation.
Plug-in modules - Customize your controller with our plug-in extension and communication modules.
4G/LTE - Connect to your gen-set via 4G/LTE for alerts or use ComAp's WebSupervisor.
GPS - Always know the location of your gen-set using geofencing for theft or movement alerts.
InteliConfig - Our new configuration and monitoring PC tool (based on new LiteEdit) will offer you multi gen-set control and monitoring as well as easy set-up.
InteliGen 500 is further offering:
5" TFT with 800x480 px resolution
All important information available on well arranged measuring screens
Easy parameters setting
On-screen trends
Easy switching between parallel to mains or multiple genset applications
Multiple gensets in parallel to mains available together with InteliMains 210 controller
Two types of synchronisations: Phase Match or Slip Synchro
Two types of Load/VAr Sharing: Isochronous (CAN) or Droop, including Emergency Droop
Direct communication with EFI engines including Tier 4 Final support
Total remote monitoring and control
InteliConfig for configuration and monitoring
WinScope for precise tuning of PID regulators exactly according to gen-set type and application needs
WebSupervisor for cloud based monitoring and control of your whole gen-set fleet
Wide range of communication and connection capabilities including:
USB, CAN, RS485 and Ethernet on board
USB master for configuration or firmware upload or download
RS232 and additional RS485 via plug-in module
Internet access by using of inbuilt Ethernet or GPRS/3G/4G via plug-in modules
Configurable Modbus RTU or TCP and support of SNMP protocols
Internal PLC support with PLC editor and monitor included in InteliConfig
Active SMS and emails in different languages
Geofencing and tracking via WebSupervisor
2 x 10 A binary outputs for cranking and fuel solenoid, powered by separated E-Stop input
4x switchable analog inputs (R/U/I)
Option for additional inputs/outputs
Flexible event based history with up to 500 events
Load shedding, dummy load capability
Comprehensive gen-set protections
Multipurpose flexible timers
UL listed
Note: some features require the use of additional expansion or communication cards.
