Product Description
· Glow wire diameter: 4mm ± 0.04mm Ni/Cr(80/20) special-ordered standard ring shape, put in horizontal;
· Thermocouple diameter: 0.5mm K type, import insulated thermocouple which can endure high temperature, and it can endure about 1100 ℃ (superior to standard 1050 ℃);
· Glow wire heating temperature under electrified: 500 ℃~960 ℃ (digital display,can be preset), fluctuation of temperature < 3 ℃;
· Inspect the temperature during the test: thermocouple is located between Glow wire tester and back panel of box, with distance of 100 m. The outer connect to a temperature to display temperature;
· Test height of flame: Ruler of flame height;
· The press of Glow wire: 1.0N±0.1N(adjustable )(superior to standard 1.0N±0.2N);
· The maximum depth of insertion: 7mm ± 0.5mm ( adjustable ) the maximum depth of insertion;
· Mobile speed of the tested goods: 10mm /s~25mm /s;
· Test time: 30s±0.1s(1s~999.9s digital display, can be preset);
· Thickness of matting used to ignite: Thickness: 10mm; deal board cover 12g /m 2~30g /mm 2 standard paper, above the glow wire about 200mm ± 5mm
· Test space: 0.5m 3, with black background, illuminance of background≤ 20Lux, the material of box is stainless steel;
· Power: 1kVA 220V 50-60Hz.
