Characteristics:
* Air-cooled, single-cylinder, 4-stroke, direct injection
* Efficient air cleaner system
* Compact in structure and small in size
* Multiple PTO shafts are available
* Recoil manual starter and optional electric starting
* CE approved diesel engines
* EPA Tier II exhaust emission compliant.



Specifications:

Model  DE178FA (E)
Engine Type  Air-cooled, 4-stroke, Vertical Cylinder
Fuel Diesel
Number or Cylinders 1
Bore x Stroke [mm] 78*64
Total Displacement [cc] 306
Combustion Type Direct injection
Aspiration Natural Aspiration
Valves per Cylinder 2
Rated Speed 3600rpm
Net Intermittent Hp/rpm 6.7/3600
Net Continuous Hp/rpm 6.0/3600
Direction of Rotation Counter Clockwise, Viewed from PTO Side
Crankshaft Type Keyway, Taper or Thread
Starting System Recoil or Recoil/12V Electric
Decompression System Manual Type with Auto-return Lever
Charging System 12 Volt, 15Amps (for Electric Start Models)
Electric Stop Device Optional, Fuel Stop Solenoid  (for Electric Start Models)
Cold Start Aid Optional, Intake Air Heater (for Electric Start Models)
Fuel Tank Capacity [Liters] 3.3
Brake Specific Fuel Consumption at Rated Output g/kw-hr 215
Lubrication System Pressure Lubrication with Trochoid Pump
Oil capacity [Liters] 1.1
Exhaust Systems Expansion Silencer with Cover
Air Cleaner Dry Type with Paper Element Filter
Balancing System Single, Counter-Rotating, Balancer Shaft
Length 475
Width 455
Height 518
Dry Weight (recoil start) [kg] 36
Dry Weight (Electric start) [kg] 41
Noise Output at Continuous Output Rating, Four Direction at 1 Meters 95.5dB(A)
