Features:

A   The process of washing, sterilizing, filling is finished automatically.

B    Filling volume is controlled by high-speed positioning filling skill system

C    The temperature of hot water and lye is controlled automatically.

D     Available to connect more than one machine together to reduce the investment.

E     Auto washing of the beer pipeline CIP

F     Figure statistics and display function

G     Check keg spear automatically, make sure the washing quality and filling volume.

H     Suitable for different beer keg sizes.

Working Procedures

Location—scavenge wine remains—mixed hot mater washing—blow  -- sterilize by lye—recycle—hot water washing—recycle—sterilize by steam—sterile water washing—recycle—Preparation of CO2 pressure --filling

Technical parameters:

Siemens LOGO PLC

Stainless steal control crow valve

Pneumatical component of Taiwan Yadake

Main Parameter

Filling accuracy: 5‰

Capacity: 30-40bottles/hour

Compressed air: pressure＞0.4Mpa

Wince resource pressure: 0.25~0.4Mpa

Power: AC220V

Voltage: DC24V

Equipment size: 900mm x1530mm x1950mm
